DS-3000

Multi-Channel Data Station

DS-3000
DS-3000
DS-3000

The DS-3000 Series puts all the advanced functions required of a signal processing system in a single, compact paper size cabinet. This series must be integrated to a PC.

  • 2 to 32 input channels. Channels may be added later as your needs dictate.
  • Ultra compact (7" x 10") and lighweight design (less than 2.5 kg).
  • OS includes: Windows XP, Windows Vista, Windows 7.
  • Built-in sensor power.
  • Quiet fanless design.

SEND Inquiry

Specifications

Number of Input Channels 2 to 32
Frequency Range 0 to 40 kHz
A/D Converter 24-Bit
Dynamic Range 110 dB
Current Sensor Power 4 mA
Operating temperature 0 to 40º C
Dimensions 269 mm (W) x 71 to 267 mm (H) x 217 mm (D)
Weight 2.2 kg (4 channel configuration)

Notes

Standard Accessories: One AC Adaptor w/ Power Cable, One DC Power Cable, One Remote Control Box, One Operation Instruction Manual (Help File) and One Hardware Instruction Manual.
