LA-1411

Integrating Sound Level Meter (Class 2)

LA-1411
LA-1411

The LA-1411 Integrating Sound Level Meter conforms to the latest IEC / JIS standards while focusing on easy operation and cost effectiveness.

  • Performs and stores 14 measurements simultaneously.
  • 100 dB Linearity Range.
  • Timer measurement function.
  • Manual and setup memory.
  • Easy to use settings menu.

SEND Inquiry

Specifications

Applicable Standards JIS C 1509-1:2005 Class 2, IEC 61672-1:2002 Class 2
Linearity Range 100 dB
Measurement Range 26 to 137 dB(A), 31 to 137 dB(C), 36 to 137 dB(Z)
Frequency Weighting A, C, Z
Measured Parameters Lp, Leq, Le, Ln, Lmax, Lmin, Lpeak
Time Weighting Fast, Slow
Memory Modes Manual, Automatic
AC Output 0.707 Vrms/Full Scale (Normal Range), 2.238 Vrms/Full Scale (Wide Range)
DC Output 2.5 V/Full Scale, 0.25 V/10 dB
RS-232C No
Power Supply 2 x AA Batteries, AC Adaptor (Optional)
Battery Life Approximately 8 Hours
Operating Temperature Range -10 to 50ยบ C
Operating Humidity Range 25 to 90% Relative Humidity
Dimensions 78 mm (W) x 263 mm (H) x 47 mm (D)
Weight Approximately 375 g (Including Batteries)

Notes

Standard Accessories: One Windscreen, Two Type AA Batteries, One Hard Shell Transit Case and One Instruction Manual.
